Radiotherapy Design

Design Your Perfect Treatment Room

Patients and professional staff enjoy an environment that’s as aesthetically pleasing as it is functional. That’s why Veritas offers many design services to draft realistic blueprints, layouts and the plans you need to build. We’ll make sure your project is code compliant and constructed to your complete satisfaction.

Sample Engineered Drawings

6/10 MV LINAC

Sample drawings for linear accelerator rooms with 6/10 MV energy.

15 MV LINAC

Sample drawings for linear accelerator rooms with 15 MV energy.

18/25 MV LINAC

Sample drawings for linear accelerator rooms with 18/25 MV energy.

10 MV LINAC TRUEBEAM

Sample drawings for linear accelerator rooms with 6/10 MV energy and Varian TrueBeam.

6/15 MV LINAC TRUEBEAM

Sample drawings for linear accelerator rooms with 6/15 MV energy and Varian TrueBeam.

18 MV LINAC TRUEBEAM

Sample drawings for linear accelerator rooms with 18 MV energy and Varian TrueBeam.

6/10 MV MULTI LINAC

Sample drawings for multiple linear accelerator rooms with 6/10 MV energy.

LINAC AND CT-SIM

Sample drawings for a linear accelerator and CT-SIM treatment room suite.

TOMOTHERAPY

Sample drawings for a Tomotherapy direct entry treatment room.
